- Case Report Invasive cervical resorption: treatment challenges
- Yookyung Kim, Chan-Young Lee, Euiseong Kim, Byoung-Duck Roh
-
2012;37(4):-231.
DOI: https://doi.org/10.5395/rde.2012.37.4.228
Published online: November 21, 2012
Department of Conservative Dentistry, Yonsei University College of Dentistry, Seoul, Korea. JFIF d d Ducky d qhttp://ns.adobe.com/xap/1.0/ |er˭|I|-fGK.rΛp8XV1%K6mvG+tc+qE &ǸC_Nm:l=_/m5^[dߌڇ.c<%:)tQ$Ow~-aY;UJ >=F)2[nk؆?훐 M=l6[4(O.]2#-H^n#->&mp5~Fӛ+|| S,xag% qkEUzUgæBhߕP(7]kFnq?֖Cpru Z6*rEڊtS|*tI*E}7R<,nUU֫^I7Q*mSly%rdȓd8hE<9oHhMfNSRj[i7D[Rj݊+kდq{"$$H?p \̅S?㭻;t~ R߁ )^/>Qj`yt[w ԛ;² ~+ ߔ_ YW~|o] ?x^ᯛ `ʼn;g)T@vWn]>&4l p+$D̢1l|ȨF%-} .9[}w~
ԠLM9hСablfe&QoW !s ?wjLK?s7yO>(=C~_nyǜu? v 3vyo oI@qV-jeES^[9WoSܝh"l2C1a͔CiJ@3:Pճw= /7ovuk+\V;lDgն <[A+r X~d;m!_s8ݖ;;.0llUC+?i#_crʙ1~C.\q u l8Hܶ2m`ܻM3Tov|Bs rɵ"oLS-
DКw=Tv@f '6|YlD͓Y%-#Ѯo%:&!3o%\J<02;K87>^vgƓ# ;ݝmz^Y6=PS39U%~
&f#
}o!muH; ʲŇ˷yvP+&.7e[3'vR4Yj̗IZ`e˽3o[WU{
m[sUbۋZǾۆl6~9'V*.\S2<Sd*zY[aŶ`]C$n.v^Ʌ
dng>ەZ,Mmϑ :n6nϦezW qUJ4! ۇ4R! =>>F n|Q[{pRO 17ƕ~._I ''00k=b՛o}Osðc2'o\3}ݭQ^ 2 . R1yKȣtAݿ-u ܾw!`?1Whn|gzU o[ECWwjUIן)^h#1ɭ!/Z
np;o;ΗŻkXs."6E`Z1
עӐ9Kl8qd q} 2Stt;#j>;խabONŗ=fwP1j)l6J̶|gV 2`y/0E˛6+ԫ1?
6}KW c\KoKͨ2ۅFws*TԞLיuDx .kCzWXhy۶gLu|%TnupǺl-S* P RaLnT+c+*xl.v!.U=|; !_L̎뱚U=4hm:ٯ"y)$:>%(n}X'p[ȴ
^˒4kƓmzDx
\
'Nq amP7nyN݅=
- Correspondence to Byoung-Duck Roh, DDS, MSD, PhD. Professor, Department of Conservative Dentistry, Yonsei University College of Dentistry, 50 Yonsei-Ro, Seodaemun-gu, Seoul, Korea 120-752. TEL, +82-2-2228-8701; FAX, +82-2-313-7575; operatys16@yuhs.ac
• Received: June 12, 2012 • Revised: July 30, 2012 • Accepted: August 23, 2012
©Copyights 2012. The Korean Academy of Conservative Dentistry.
This is an Open Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/3.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.
- 1,664 Views
- 13 Download
- 11 Crossref
Abstract
- Invasive cervical resorption is a relatively uncommon form of external root resorption. It is characterized by invasion of cervical region of the root by fibrovascular tissue derived from the periodontal ligament. This case presents an invasive cervical resorption occurring in maxillary lateral incisor, following damage in cervical cementum from avulsion and intracoronal bleaching procedure. Flap reflection, debridement and restoration with glass ionomer cement were performed in an attempt to repair the defect. But after 2 mon, more resorption extended apically. Considering root stability and recurrence potential, we decided to extract the tooth. Invasive cervical resorption in advanced stages may present great challenges for clinicians. Therefore, prevention and early detection must be stressed when dealing with patients presenting history of potential predisposing factors.
Introduction
Invasive cervical resorption (ICR) is a type of external root resorption which is characterized by invasion of root dentin by fibrovascular tissue derived from the periodontal ligament.1 ICR usually starts from cervical cement-enamel junction (CEJ) where the epithelial attachment is located, and purely inflammative, irrelevant to bacterial infections until secondary invasion from gingival sulcus occurs. Furthermore, it exhibits very aggressive behavior compared with typical external root resorptions.1-3 Therefore when dealing with this specific kind of resorption, different approaches are needed, aiming complete removal of the resorptive tissue and definite seal of the affected dentinal tubules.4
Heithersay classified ICRs into 4 categories according to the extent of the resorption.5 As would be expected, smaller lesions (Classes 1 and 2) offer favorable outcomes. But in the advanced stages (Class 4), success rate drastically fall down to 12.5%. The most common reason of failure was ongoing resorption and root fracture. This low success rate raises the question of the desirability of attempting a treatment. It is very difficult to eliminate the resorptive tissues without harming the root stability, and as far as blood supply from the periodontium remains, the resorption may continue.
Case reports
Following a car accident, a 24-year-old woman was presented to the emergency department in Yonsei University College of Dentistry, Seoul, Korea. Three of maxillary anterior teeth, both maxillary central incisors and right lateral incisior were totally avulsed and stored dry for 1 hour. Saline irrigation of the contaminated root surfaces, replant and resin-wire splint was performed. After 1 week, she was referred to Department of Conservative Dentistry and routine nonsurgical root canal treatment was conducted. The teeth were stable on the 12 months recall visit and presented no unusual changes other than minor surface resorption. At the 15 months recall, the patient complained about brownish discoloration of the crown, so right central and lateral incisors were bleached for 1 week with sodium perborate and distilled water. Two weeks later, access cavity was restored with composite resin. Afterwards, the patient did not show up for another 15 months due to personal affairs.
Thirty months after the trauma, the patient came to our department again for regular checkups. The patient was still free of symptoms, but there was a sinus tract formed on labial mucosa of right maxillary lateral incisor. Periapical radiograph was taken with gutta-percha tracing to confirm the origin. Surprisingly on the distal root surface of right lateral incisor, a noticeable cervical defect was revealed. The resorptive lesion was provisionally diagnosed as invasive cervical resorption and surgical repair was attempted (Figure 1).
All procedures were performed under operating microscope (OPMI, PICO, Carl Zeiss, Gottingen, Germany). After local anesthesia (2% lidocaine with 1:100,000 adrenaline), full-thickness periosteal flap was elevated. Soft tissue curettage and initial debridement with low-speed round bur disclosed the characteristic resorptive lesion involving labial and distal surfaces of the root (Figure 2). First, numerous small bleeding points (referred to as 'penetration points' by Schwartz) were observed.6 These indicate that the lesion possesses active resorptive potentials carrying blood supply from the periodontium into deeper parts. The base containing these points was solid on probing. This is a feature of advanced ICR lesions with fibro-osseous tissue replacing resorbed dentin. Failure to differentiate this ectopic calcified material from dentin can lead to failure in treatment, because resorption will continue beneath the apparently sound cavity base.5 Tooth preparation was carried out and intact dentin base was confirmed under high magnification (×16 - 20). The cavity was restored with reinforced glass ionomer (GC Fuji II LC, GC Corporation, Tokyo, Japan) and light cured. Further refinement was achieved with a fine tapered diamond bur. Flap was repositioned and sutured interproximally with 4-0 mersilk (Mersilk, Ethicon, Edinburgh, UK).
One month recall showed satisfactory gingival healing and the patient was free of symptoms. However on the radiograph, suspicious radiolucent spot was observed under the glass ionomer filling, and after another month, sinus tract recurred. Periapical radiograph with gutta-percha tracing definitely shows apically advanced radiolucent lesion under the glass ionomer filling (Figure 3). Treatment options were discussed with the patient and decided to go on a re-surgery. Full-thickness periosteal flap was once more elevated. As predicted, the progressed resorption site was clearly seen under the buccal side of glass ionomer filling. After initial debridement, penetration points in the cavity were visible, again suggesting that there are tissues with active resorption potential left inside. Additional tooth preparation of the remaining resorptive tissue and glass-ionomer filling was done, but considering root stability and associated periradicular pathosis, we decided to extract the tooth (Figure 1).
Discussion
This case report illustrates a characteristic invasive cervical resorption which developed and progressed rapidly, and eventually ended on extraction of the tooth. Until today, the exact cause of ICR has not been fully understood, but it is broadly accepted that damage to or deficiency of cementum below the epithelial attachment is somehow related.2 Without protective cementum layer, the root dentin is directly exposed to the periodontal ligament cells which can differentiate into cells capable of laying down fibrous or calcified tissue. Heithersay investigated 257 teeth displaying ICR to assess these factors and concluded that orthodontic treatment, trauma, intracoronal bleaching, and surgery had strong association between development of ICR.7 In this case, trauma, specifically avulsion, and intracoronal bleaching was associated.
It is generally believed that application of heat, 30% hydrogen peroxide, and lack of cervical barrier are related to root resorptions from intracoronal bleaching procedures.8,9 In this case, walking bleaching using sodium perborate and distilled water was performed, but unfortunately cervical base was omitted. In normal situations, walking bleaching has been known relatively safe.10 But sodium perborate mixed with water actually generates low levels of H2O2, and in this case, unfortunately there were previous surface resorption caused by avulsion. A quantitative study has demonstrated that artificial defects in cementum cause increase in H2O2 penetration up to 82% of total amount, and avulsed tooth resembles this situation in vivo.11 Unimpeded passage of H2O2 could be expected through denuded cementum into the periodontal ligament, resulting in simulation of resorption process.12,13 But we should note that this is only a possible assumption and the true mechanism can be hidden. Actually, not every tooth in similar condition develops ICR and this area still remains to be explained.
Before the first surgical repair, we classified the case as Heithersay class 3 according to the radiographic extent. However, considering the fact that an apical lesion developed which was not seen before, the total root canal space must have been invaded with microorganisms. If so, then maybe the lesion was already class 4 at the time. Resorptions of this magnitude usually have a complicated structure comprised of not only fibrovascular tissues, but of ectopic calcifications deposited on the resorbed dentin surface. These features were seen from the first surgical intervention (Figure 2). Furthermore, a series of channels containing resorptive tissue are present, and they usually have connections further apically with the periodontal ligament. These channels can involve serious problems. No matter how thoroughly the tissue of the main lesion is removed, as long as the apical channels remain and deliver blood supply from the periodontium, the possibility of recurrence will always exist.
After extracting the tooth in this case, methylene blue staining of the root surface was performed. Interestingly, there were defects all over the root surface (Figure 4). We do not know how many of these defects are actually linked to the main lesion as a 'channel', but there are studies presenting histological sections and after clearing images which demonstrate definite connections to a certain extent in similar extracted ICR teeth, and the same might be said of this case.1,6 Consequently, resorption control by tooth preparation is almost impossible to reach into these areas, and even if it was possible, it would result in excessive weakening of the root. So, according to Heithersay, no treatment or alternative therapy is indicated for class 4 lesions, in which resorption has extended beyond one third of the root length.5
Therefore till now, prevention and early detection is essential for successful management of ICR, since advanced lesions can present great challenges for clinicians. When dealing with patients with a history of one or more potential predisposing factors, we must be careful when adding more factors, and should monitor very closely for initial signs of ICR, because smaller lesions offer the most favorable outcome.
Conclusions
This case presents an invasive cervical resorption that finally resulted in extraction of the tooth. It may have been caused by damage in cervical cementum, physically from avulsion and chemically from intracoronal bleaching procedure. Invasive cervical resorption in advanced stages may present great challenges for clinicians. Therefore, prevention and early detection must be stressed when dealing with patients presenting history of potential predisposing factors.
- 1. Heithersay GS. Clinical, radiologic, and histopathologic features of invasive cervical resorption. Quintessence Int 1999;30:27-37.PubMed
- 2. Patel S, Kanagasingam S, Pitt Ford T. External cervical resorption: a review. J Endod 2009;35:616-625.ArticlePubMed
- 3. Frank AL, Torabinejad M. Diagnosis and treatment of extracanal invasive resorption. J Endod 1998;24:500-504.ArticlePubMed
- 4. Kqiku L, Ebeleseder KA, Glockner K. Treatment of invasive cervical resorption with sandwich technique using mineral trioxide aggregate: a case report. Oper Dent 2012;37:98-106.ArticlePubMedPDF
- 5. Heithersay GS. Treatment of invasive cervical resorption: an analysis of results using topical application of trichloracetic acid, curettage, and restoration. Quintessence Int 1999;30:96-110.PubMed
- 6. Schwartz RS, Robbins JW, Rindler E. Management of invasive cervical resorption: observations from three private practices and a report of three cases. J Endod 2010;36:1721-1730.ArticlePubMed
- 7. Heithersay GS. Invasive cervical resorption: an analysis of potential predisposing factors. Quintessence Int 1999;30:83-95.PubMed
- 8. Attin T, Paqué F, Ajam F, Lennon AM. Review of the current status of tooth whitening with the walking bleach technique. Int Endod J 2003;36:313-329.ArticlePubMedPDF
- 9. Dahl JE, Pallesen U. Tooth bleaching-a critical review of the biological aspects. Crit Rev Oral Biol Med 2003;14:292-304.PubMed
- 10. Madison S, Walton R. Cervical root resorption following bleaching of endodontically treated teeth. J Endod 1990;16:570-574.ArticlePubMed
- 11. Rotstein I. In vitro determination and quantification of 30% hydrogen peroxide penetration through dentin and cementum during bleaching. Oral Surg Oral Med Oral Pathol 1991;72:602-606.ArticlePubMed
- 12. Andreasen JO, Hjorting-Hansen E. Replantation of teeth. II. Histological study of 22 replanted anterior teeth in humans. Acta Odontol Scand 1966;24:287-306.ArticlePubMed
- 13. Plotino G, Buono L, Grande NM, Pameijer CH, Somma F. Nonvital tooth bleaching: a review of the literature and clinical procedures. J Endod 2008;34:394-407.ArticlePubMed
REFERENCES
Figure 1
Serial periapical radiographs. (a) Initial visit, after replantation; (b) After root canal treatment; (c) 12 months follow-up; (d) 15 months follow-up. Walking bleaching performed; (e) 30 months follow-up. ICR developed on distal surface of #12; (f) After surgical repair; (g) 1 month after the surgery; (h) 2 months after the surgery; (i) After the second surgery. Afterwards the tooth was extracted.
Figure 2
Microscopic view during surgical repair. Arrowheads indicate penetration points. Note the fibro-osseous tissue resembling dentin on the surface. (a) ×6; (b) ×16 magnification.
